LV429000: NSX100F 2P (3P) 36kA Frame
Call for Price
This is a bare frame unit and is supplied without a trip unit.
Please click here to see a range of associated trip units.
- Description
- Additional information
Description
Description
| range |
Compact
|
|
|---|---|---|
| range of product |
NSX100…250
|
|
| product or component type |
Basic frame
|
|
| device short name |
Compact NSX100F
|
|
| device application |
Distribution
|
|
| circuit breaker name |
Compact NSX100F
|
|
| poles description |
2P
|
|
| network type |
AC
|
|
| network frequency |
50/60 Hz
|
|
| [In] rated current |
100 A ( 40 ?C )
|
|
| [Ui] rated insulation voltage |
800 V AC 50/60 Hz conforming to IEC 60947-2
|
|
| [Uimp] rated impulse withstand voltage |
8 kV conforming to IEC 60947-2
|
|
| [Ue] rated operational voltage |
AC 50/60 Hz conforming to IEC 60947-2
|
|
| breaking capacity code |
F
|
|
| breaking capacity |
8 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2
22 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 35 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 85 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 10 kA at 600 V AC 50/60 Hz conforming to UL 508 25 kA at 480 V AC 50/60 Hz conforming to UL 508 85 kA at 240 V AC 50/60 Hz conforming to UL 508 |
|
| suitability for isolation |
Yes conforming to EN 60947-2
Yes conforming to IEC 60947-2 |
|
| utilisation category |
Category A
|
|
| pollution degree |
3 conforming to IEC 60947-1
|
Additional information
Additional information
| Frame Type | |
|---|---|
| Brand | |
| Poles Description | |
| Mode | |
| Trip Unit Technology | |
| Breaking Capacity | 36kA |
